UltraRAM’s Quantum Leap: How Quinas Is Turning Universal Memory Into Commercial Silicon

UltraRAM Just Made Every Other Memory Type Look Outdated

Estimated reading time: 10 minutes

Key Takeaways

• UltraRAM is designed as universal memory that combines RAM-like speed with storage-like persistence.
• Quinas Technology has prototypes, government funding, a major manufacturing partner, and a roadmap to commercial silicon.
• UltraRAM’s TBRT structure enables extreme retention, endurance, and low energy switching compared to DRAM and NAND.
• Key near-term focus areas include industrial-scale wafer production, CMOS integration, and targeting high-performance markets first.

Memory technology has not changed much in decades. You have got RAM, which is fast but forgets everything the moment you cut the power. You have got flash storage, which holds data but wears out quickly and runs slow. For years, engineers have dreamed of a single chip that does both jobs perfectly. That chip is called UltraRAM, and it is closer to reality than most people realize.

This is not a lab rumor or a speculative white paper. A real company, Quinas Technology, has prototype chips, government funding, a major manufacturing partner, and a clear roadmap to commercial silicon. What started as a physics project at Lancaster University in the UK is now moving through formal industrialization programs backed by millions in public and private investment.

In this article, we break down exactly what UltraRAM is, how it works, what has been built so far, and why it matters for the future of AI, neuromorphic computing, and every device that relies on memory chips.

What UltraRAM Actually Is and Why It Matters for Universal Memory

The term universal memory gets thrown around a lot. What it means, in plain English, is a single type of memory chip that replaces both RAM and storage. Right now, your computer uses at least two separate memory systems because no one technology does everything well. DRAM is fast but volatile — it loses data when power stops. NAND flash holds data permanently but is slow, and it degrades after a limited number of writes.

UltraRAM is designed to solve both problems at once. Here is how it stacks up against what we use today:

• Data retention: UltraRAM can hold data for an extrapolated 1,000+ years without power. Some Lancaster University calculations suggest the underlying physics could theoretically retain data longer than the current age of the universe.
• Write endurance: It handles at least 10 million program-erase cycles. Standard TLC 3D NAND flash starts degrading after just a few thousand writes.
• Speed: UltraRAM is designed for 1-nanosecond write operations, which is approximately 10 times faster than DRAM.
• Energy use: Switching energy is 100 times lower than DRAM fabricated on the same node, and about 1,000 times lower than NAND.
• Latency: The target is one-tenth the latency of current DRAM.

These numbers are not minor improvements. They represent a different category of device entirely.

The technology behind this performance is a structure called a Triple-Barrier Resonant Tunneling (TBRT) layer. Like flash memory, UltraRAM uses a floating gate to store charge. But instead of the silicon oxide layer that flash uses — which gradually degrades every time data is written — UltraRAM uses this TBRT structure. The key difference is that this barrier does not wear out during write and erase cycles, which is the root cause of the extreme endurance numbers.

The quantum mechanical process called resonant tunneling allows electrons to pass through this barrier extremely quickly and with very little energy. That is where the speed and efficiency advantages come from. It is not a clever engineering trick layered on top of old physics. It is a fundamentally different operating principle.

Lancaster University's research team progressed from 4-bit ULTRARAM arrays to a patent-pending memory architecture over the period from 2018 to 2022. Their simulations and physical tests confirmed a highly compact, high-bit-density design with ultra-low energy per unit area. That foundation is now what Quinas Technology is working to commercialize.

Lancaster University invents universal memory technology

Simulations of resonant tunnelling through InAs/AlSb heterostructure

How Quinas Technology Is Building the Path From Lab to Commercial Silicon

Quinas Technology was spun out of Lancaster University's Physics Department with one specific mission: take UltraRAM from academic prototype to sellable chip. Since its formation, the company has moved through several formal funding and validation programs that tell a clear story of progress.

The Innovate UK Awards

The UK's national innovation agency, Innovate UK, runs a rigorous program called ICURe (Innovation to Commercialisation of University Research). Quinas graduated from this program and then secured a £300,000 Innovate UK award specifically to commercialize ULTRARAM as "universal computer memory." This funding also included sponsorship for a Department for Business and Trade mission to Taiwan to identify potential manufacturing partners.

This is significant. Innovate UK does not hand out money for ideas. The award is given for demonstrating commercial viability and leading-edge science. Getting this grant means Quinas had to prove, in front of experienced evaluators, that the technology had a realistic path to market.

On top of that, Quinas was also supported under UKRI's "Developing Semiconductor Hardware for Critical Technologies" scheme. Under this program, Quinas explored ULTRARAM for neuromorphic computing and secure, energy-efficient AI systems. The fact that it was classified under "Critical Technologies" places it alongside other hardware the UK government considers strategically essential for national capabilities.

The IQE Partnership and the £1.1 Million Industrialisation Project

The single most important development in recent UltraRAM history is the partnership with IQE plc, one of the world's leading compound semiconductor wafer suppliers. Together, Quinas and IQE completed a £1.1 million Innovate UK-funded industrialisation project with Lancaster University and Cardiff University as partners.

The goal of this project was specific and practical: develop a scalable production method for ULTRARAM wafers. Most of that £1.1 million was deployed at IQE specifically to advance epitaxial wafer production at industrial scale.

This is not a research grant. This is a manufacturing development project. The difference matters enormously. You can have a perfect chip design, but if no one can produce the wafers reliably and cheaply enough to sell, the technology goes nowhere. This project directly attacks that challenge.

UltraRAM requires very precise semiconductor layers — specifically GaSb, InAs, and AlSb — deposited using a process called Molecular Beam Epitaxy (MBE). This is the same process the Lancaster lab uses in its cleanroom equipment. Scaling MBE to industrial production is one of the key technical challenges the IQE partnership is tackling.

Why Taiwan Matters

Tom's Hardware's original lab visit report noted that QuInAs had been at SEMICON Taiwan 2023 as part of a UK Pavilion exhibition. The signals from those discussions suggested that manufacturing partners may be found in Taiwan rather than Europe.

This is a strategic choice. Taiwan's semiconductor ecosystem — anchored by TSMC and a deep network of specialized suppliers — is the most advanced in the world. If Quinas can find integration pathways there, it dramatically increases the chance of getting UltraRAM into real products at volume.

Innovate UK award for Lancaster spinout Quinas Technology

IQE and Quinas Technology complete £1.1m UltraRAM industrialisation project

Quinas - Semiconductor Today

Quinas Technology Ltd case study
